HP 动能 Integrity rx2600 rx2620 服务器小型机及备件
HP Integrity rx2600 rx2620 Server
Processor: 1 or 2 Intel Itanium 2 processors 1.6GHz 1.5GHz, 1.4GHz, 1.3GHz, or 1.0GHz
Memory: Up to 24GB DDR memory
Disk: Up to 3 x 36GB/73GB/146GB hot-plug Ultra320 SCSI disks
4 full-length, 64bit/133MHz PCI-X slots
Supports HP-UX 11i v2, Microsoft Windows Server 2003, Linux
相关备件
Model rx2620 base system with one 1.6GHz/3MB CPU (200 MHZ front side bus). (System includes one CPU, core I/O, and one power supply) AB332A
Model rx2620 base system with one 1.3GHz/3MB Intel? Itanium? 9M CPU. (System includes one CPU, core I/O, and one power supply) AB333A
Model rx2620 base system with one 1.6GHz/6MB Intel Itanium Madison 9M CPU. (System includes one CPU, core I/O, and one power supply) AB331A
Bundled Base Systems
Model rx2620 base system with one 1.6GHz/6MB CPU, 1GB (4X256MB DIMMS) memory, 1 x 36GB disk drive, and 1 DVD-RW AB356A
Model rx2620 base system with one 1.6GHz/3MB/200MHz FSB CPU, 1GB (4X256MB DIMMS) memory, 1 x 36GB disk drive, and 1 DVD-RW AB357A
Model rx2620 base system with one 1.3GHz/3MB CPU, 1GB (4X256MB DIMMS) memory, 1 x 36GB disk drive, and 1 DVD-RW AB393A
Model rx2620 base system with two 1.6GHz/6MB CPU, 2GB (4X512MB DIMMS) memory, 2 x 36GB disk drive, and 1 DVD-RW AB387A
Model rx2620 base system with two 1.6GHz/3MB/200MHz FSB CPU, 2GB (4X512MB DIMMS) memory, 2 x 36GB disk drive, and 1 DVD-RW AB386A
Model rx2620 base system with two 1.3GHz/3MB CPU, 2GB (4X512MB DIMMS) memory, 2 x 36GB disk drive, and 1 DVD-RW AB394A
Additional Processor Modules (Optional -- max 1)
1.6 GHz/6 MB Intel Itanium 2 Madison 9M processor AB334A
1.6 GHz/3 MB Intel Itanium 2 processor Madison 9M AB335A
1.3 GHz/3 MB Intel Itanium 2 processor Madison 9M AB336A
Management Processor Card (Optional-- max 1)
Management Processor with VGA A9803A
Advanced Remote Server Management (Optional -- max 1)
Integrated Lights-Out (iLO) Advanced Pack Remote Management AB500A
Memory Modules (Required -- min 1 quad and 1GB; max 3 quads and 24GB )
1GB Chip Spare PC2100 DDR-SDRAM memory quad (4x256MB 1.2" DIMMs) AB395A
2GB Chip Spare PC2100 DDR-SDRAM memory quad (4x512MB 1.2" DIMMs) AB396A
4GB Chip Spare PC2100 DDR-SDRAM memory quad (4x1GB 1.2" DIMMs) AB397A
8GB Chip Spare PC2100 DDR-SDRAM memory quad (4x2GB 1.2" DIMMs) AB228A
Internal Disk Drives (Optional -- max 3)
36 GB, 15K RPM Ultra320 SCSI HotPlug Disk A9896A
73 GB, 15K RPM Ultra320 SCSI HotPlug Disk A9897A
146GB, 10K RPM Ultra320 SCSI HotPlug Disk A9898A
Removeable Media Drives (Optional -- max 1; DVD-ROM is required for Microsoft? Windows? orders)
DVD-ROM Drive, Slimline (required for Windows orders) A9919A
DVD-RW/DVD-ROM Drive AB348A
Power Supply
Second power supply for n+1 power redundancy A6874A
PCI I/O cards (Optional -- max 4)
Mass Storage Adapters
Dual Channel PCI-X 2GBPS FC HBA for Windows AB466A
PCI-X 2GBPS FC HBA for Windows AB467A
PCI 2Gb Fibre Channel Adapter A6795A
2-port 2Gb FC HP-UX, Linux?, Windows A6826A
PCI Ultra160 SCSI Adapter A6828A
PCI Dual Channel Ultra160 SCSI Adapter A6829A
Windows and Linux Ultra160 SCSI Adapter A7059A
Windows, Linux 2 port Ultra160 SCSI HBA A7060A
2-port U320 SCSI HPUX A7173A
PCI-X RAID Smart Array 6402 U320 2CH (Max 3) A9890A
PCI-X RAID Smart Array 6402 U320 4CH (Max 3) A9891A
Smart Array Internal Cables for rx26XX (requires min/max 1 A9890A or A9891A) A9827A
Local Area Network (LAN) Adapters
PCI 10/100Base-T LAN Adapter A5230A
4 port 100baseTX Ethernet LAN Adapter A5506B
PCI 1000Base-T Gigabit Ethernet Adpt A6825A
PCI 1000Base-SX Gigabit Ethernet Adpt A6847A
2-port 1000Base-SX HP-UX A7011A
2-port 1000Base-T HP-UX A7012A
Win/Linux 1000Base-T Gigabit Eth Adpt A7061A
Win/Linux 1000Base-SX Gigabit Eth Adpt A7073A
2-port 1000Base-SX Linux, Windows A9899A
2-port 1000Base-T Linux, Windows A9900A
Wide Area Network (WAN) Adapters
PCI ATM 155Mbps MMF Adapter A5513A
Universal PCI FDDI Adapter A3739B
PCI Token Ring 4/16/100 Hardware Adapter A5783A
2 Port X.25/Frame Relay/SDLC Interface card J3525A
X.25 High Performance Software (Optional: Max1) J2793B
PCI 8 port serial MUX adapter A6748A
PCI 64 port serial MUX adapter A6749A
Misc Cards
PCI 2 Port 100Base-T 2 Port Ultra2 SCSI (Max 3) A5838A
GigE-SX/2G FC Combo Card HP-UX A9782A
GigE-TX/2G FC Combo Card HP-UX A9784A
Video Monitors (Optional -- Max 1)
19" LCD Flat Panel Display P9626A
20" LCD Flat Panel Display P9614A
22" CRT Color Monitor (20" viewable) P9613A
Keyboard/Mouse (Optional)
USB keyboard and USB scroll mouse. A7861C
USB to PS/2 adapter (allows the use of a PS/2 keyboard and mouse, or KVM switch) A7782A
Volume Channel Keyboard AB476A
System Console - select with localization option (Optional -- Max 1)
HP Server Thin Client Solution AB300B
Reflection for HP - CD Media AB227A
|
